产品介绍
本系列正齿轮适用于中高精度动力传动系统，主要用于需要稳定传动比与低背隙控制的工业场景。产品在连续运转工况下具备良好的耐磨性与尺寸稳定性，适用于自动化设备的批量应用。
在高负载与长期运行条件下，可有效降低齿面磨损风险，提高整体传动效率与使用寿命。
| 型号 / Model | 模数 / Module | 齿数 / Teeth | 孔径 / Bore | 轮毂径 / Hub Diameter | 分度圆 / PCD | 齿宽 / Face Width | 键槽尺寸 / Keyway | 齿面强度 (N.M) / Surface Strength | 弯曲强度 (N.M) / Bending Strength | CAD |
|---|---|---|---|---|---|---|---|---|---|---|
| MSGA1-18 | 1 | 18 | 8 | 15 | 18 | 10 | 3 x 1.4 | 6.37 | 12.1 | STEP |
| MSGA1-20 | 1 | 20 | 8 | 17 | 20 | 10 | 3 x 1.4 | 8.04 | 14.2 | STEP |
| MSGB1-20 | 1 | 20 | 10 | 17 | 20 | 10 | 4 x 1.8 | 8.04 | 14.2 | STEP |
| MSGB1-24 | 1 | 24 | 12 | 20 | 24 | 10 | 4 x 1.8 | 12.0 | 18.5 | STEP |
| MSGA1-25 | 1 | 25 | 10 | 20 | 25 | 10 | 4 x 1.8 | 13.1 | 19.6 | STEP |
| MSGB1-25 | 1 | 25 | 12 | 20 | 25 | 10 | 4 x 1.8 | 13.1 | 19.6 | STEP |
| MSGA1-30 | 1 | 30 | 10 | 25 | 30 | 10 | 4 x 1.8 | 19.0 | 25.1 | STEP |
| MSGB1-30 | 1 | 30 | 12 | 25 | 30 | 10 | 4 x 1.8 | 19.0 | 25.1 | STEP |
| MSGB1-40 | 1 | 40 | 15 | 30 | 40 | 10 | 5 x 2.3 | 34.6 | 36.5 | STEP |
| MSGA1-48 | 1 | 48 | 12 | 30 | 48 | 10 | 4 x 1.8 | 50.6 | 45.8 | STEP |
| MSGB1-48 | 1 | 48 | 15 | 30 | 48 | 10 | 5 x 2.3 | 50.6 | 45.8 | STEP |
| MSGA1-50 | 1 | 50 | 12 | 35 | 50 | 10 | 4 x 1.8 | 55.1 | 48.1 | STEP |
| MSGB1-60 | 1 | 60 | 20 | 40 | 60 | 10 | 6 x 2.8 | 80.6 | 59.9 | STEP |
| MSGA1-70 | 1 | 70 | 20 | 45 | 70 | 10 | 6 x 2.8 | 111 | 71.9 | STEP |
| MSGA1-80 | 1 | 80 | 20 | 45 | 80 | 10 | 6 x 2.8 | 147 | 83.9 | STEP |
| MSGA1-100 | 1 | 100 | 20 | 45 | 100 | 10 | 6 x 2.8 | 224 | 103 | STEP |
| MSGA1.5-15 | 1.5 | 15 | 10 | 18 | 22.5 | 15 | 4 x 1.8 | 14.8 | 30.8 | STEP |
| MSGA1.5-18 | 1.5 | 18 | 10 | 22 | 27 | 15 | 4 x 1.8 | 22.1 | 41.0 | STEP |
| MSGB1.5-18 | 1.5 | 18 | 12 | 22 | 27 | 15 | 4 x 1.8 | 22.1 | 41.0 | STEP |
| MSGA1.5-20 | 1.5 | 20 | 12 | 25 | 30 | 15 | 4 x 1.8 | 27.9 | 48.0 | STEP |
| MSGB1.5-20 | 1.5 | 20 | 15 | 25 | 30 | 15 | 5 x 2.3 | 27.9 | 48.0 | STEP |
| MSGB1.5-24 | 1.5 | 24 | 15 | 28 | 36 | 15 | 5 x 2.3 | 41.5 | 62.4 | STEP |
| MSGB1.5-25 | 1.5 | 25 | 16 | 30 | 37.5 | 15 | 5 x 2.3 | 45.4 | 66.0 | STEP |
| MSGB1.5-30 | 1.5 | 30 | 18 | 30 | 45 | 15 | 6 x 2.8 | 66.4 | 84.7 | STEP |
| MSGB1.5-36 | 1.5 | 36 | 18 | 32 | 54 | 15 | 6 x 2.8 | 97.1 | 108 | STEP |
| MSGA1.5-40 | 1.5 | 40 | 16 | 35 | 60 | 15 | 5 x 2.3 | 121 | 123 | STEP |
| MSGA1.5-50 | 1.5 | 50 | 18 | 40 | 75 | 15 | 6 x 2.8 | 193 | 162 | STEP |
| MSGB1.5-50 | 1.5 | 50 | 22 | 40 | 75 | 15 | 6 x 2.8 | 193 | 162 | STEP |
| MSGB1.5-60 | 1.5 | 60 | 25 | 45 | 90 | 15 | 8 x 3.3 | 283 | 202 | STEP |
| MSGA1.5-70 | 1.5 | 70 | 20 | 45 | 105 | 15 | 6 x 2.8 | 372 | 231 | STEP |
| MSGA1.5-80 | 1.5 | 80 | 20 | 45 | 120 | 15 | 6 x 2.8 | 494 | 270 | STEP |
| MSGB1.5-80 | 1.5 | 80 | 25 | 45 | 120 | 15 | 8 x 3.3 | 494 | 270 | STEP |
| MSGA1.5-100 | 1.5 | 100 | 25 | 50 | 150 | 15 | 8 x 3.3 | 787 | 347 | STEP |
| MSGB2-15 | 2 | 15 | 15 | 24 | 30 | 20 | 5 x 2.3 | 35.7 | 73.1 | STEP |
| MSGA2-18 | 2 | 18 | 12 | 30 | 36 | 20 | 4 x 1.8 | 53.5 | 97.2 | STEP |
| MSGB2-18 | 2 | 18 | 15 | 30 | 36 | 20 | 5 x 2.3 | 53.5 | 97.2 | STEP |
| MSGA2-20 | 2 | 20 | 15 | 32 | 40 | 20 | 5 x 2.3 | 67.6 | 114 | STEP |
| MSGB2-20 | 2 | 20 | 18 | 32 | 40 | 20 | 6 x 2.8 | 67.6 | 114 | STEP |
| MSGB2-24 | 2 | 24 | 18 | 35 | 48 | 20 | 6 x 2.8 | 101 | 148 | STEP |
| MSGA2-25 | 2 | 25 | 16 | 35 | 50 | 20 | 5 x 2.3 | 110 | 157 | STEP |
| MSGB2-25 | 2 | 25 | 20 | 35 | 50 | 20 | 6 x 2.8 | 110 | 157 | STEP |
| MSGB2-30 | 2 | 30 | 22 | 40 | 60 | 20 | 6 x 2.8 | 161 | 201 | STEP |
| MSGA2-35 | 2 | 35 | 18 | 40 | 70 | 20 | 6 x 2.8 | 223 | 246 | STEP |
| MSGA2-40 | 2 | 40 | 20 | 45 | 80 | 20 | 6 x 2.8 | 294 | 292 | STEP |
| MSGB2-40 | 2 | 40 | 25 | 45 | 80 | 20 | 8 x 3.3 | 294 | 292 | STEP |
| MSGA2-60 | 2 | 60 | 25 | 55 | 120 | 20 | 8 x 3.3 | 658 | 457 | STEP |
| MSGA2.5-15 | 2.5 | 15 | 15 | 30 | 37.5 | 25 | 5 x 2.3 | 71.0 | 143 | STEP |
| MSGB2.5-15 | 2.5 | 15 | 18 | 30 | 37.5 | 25 | 6 x 2.8 | 71.0 | 143 | STEP |
| MSGB2.5-20 | 2.5 | 20 | 22 | 40 | 50 | 25 | 6 x 2.8 | 134 | 222 | STEP |
| MSGB2.5-24 | 2.5 | 24 | 22 | 40 | 60 | 25 | 6 x 2.8 | 201 | 289 | STEP |
| MSGB2.5-25 | 2.5 | 25 | 25 | 45 | 62.5 | 25 | 8 x 3.3 | 220 | 306 | STEP |
| MSGB2.5-36 | 2.5 | 36 | 30 | 55 | 90 | 25 | 8 x 3.3 | 471 | 498 | STEP |
| MSGA2.5-40 | 2.5 | 40 | 25 | 55 | 100 | 25 | 8 x 3.3 | 560 | 543 | STEP |
| MSGB2.5-40 | 2.5 | 40 | 32 | 55 | 100 | 25 | 10 x 3.3 | 560 | 543 | STEP |
| MSGA2.5-55 | 2.5 | 55 | 30 | 70 | 137.5 | 25 | 8 x 3.3 | 1090 | 804 | STEP |
| MSGB2.5-60 | 2.5 | 60 | 40 | 70 | 150 | 25 | 12 x 3.3 | 1310 | 892 | STEP |
| MSGA2.5-70 | 2.5 | 70 | 40 | 85 | 175 | 25 | 12 x 3.3 | 1730 | 1020 | STEP |
| MSGA3-15 | 3 | 15 | 18 | 36 | 45 | 30 | 6 x 2.8 | 124 | 247 | STEP |
| MSGB3-15 | 3 | 15 | 22 | 36 | 45 | 30 | 6 x 2.8 | 124 | 247 | STEP |
| MSGB3-20 | 3 | 20 | 25 | 45 | 60 | 30 | 8 x 3.3 | 236 | 384 | STEP |
| MSGB3-25 | 3 | 25 | 30 | 55 | 75 | 30 | 10 x 3.3 | 386 | 528 | STEP |
| MSGA3-30 | 3 | 30 | 28 | 60 | 90 | 30 | 8 x 3.3 | 565 | 677 | STEP |
| MSGB3-30 | 3 | 30 | 35 | 60 | 90 | 30 | 10 x 3.3 | 565 | 677 | STEP |
| MSGA3-40 | 3 | 40 | 30 | 70 | 120 | 30 | 8 x 3.3 | 988 | 938 | STEP |
| MSGB3-40 | 3 | 40 | 40 | 70 | 120 | 30 | 12 x 3.3 | 988 | 938 | STEP |
| MSGA3-45 | 3 | 45 | 30 | 70 | 135 | 30 | 8 x 3.3 | 1260 | 1090 | STEP |
| MSGA3-60 | 3 | 60 | 35 | 80 | 180 | 30 | 10 x 3.3 | 2200 | 1470 | STEP |
| MSGB4-15 | 4 | 15 | 30 | 48 | 60 | 40 | 8 x 3.3 | 302 | 585 | STEP |
| MSGA4-20 | 4 | 20 | 28 | 60 | 80 | 40 | 8 x 3.3 | 574 | 910 | STEP |
| MSGB4-20 | 4 | 20 | 32 | 60 | 80 | 40 | 10 x 3.3 | 574 | 910 | STEP |
| MSGA4-24 | 4 | 24 | 28 | 60 | 96 | 40 | 8 x 3.3 | 819 | 1130 | STEP |
| MSGA4-25 | 4 | 25 | 30 | 60 | 100 | 40 | 8 x 3.3 | 896 | 1190 | STEP |
| MSGB4-25 | 4 | 25 | 35 | 60 | 100 | 40 | 10 x 3.3 | 896 | 1190 | STEP |
| MSGA4-30 | 4 | 30 | 35 | 70 | 120 | 40 | 10 x 3.3 | 1320 | 1530 | STEP |
| MSGB4-30 | 4 | 30 | 40 | 70 | 120 | 40 | 12 x 3.3 | 1320 | 1530 | STEP |
| MSGA4-40 | 4 | 40 | 40 | 80 | 160 | 40 | 12 x 3.3 | 2290 | 2120 | STEP |
| MSGB4-40 | 4 | 40 | 45 | 80 | 160 | 40 | 14 x 3.8 | 2290 | 2120 | STEP |
| MSGB4-45 | 4 | 45 | 45 | 80 | 180 | 40 | 14 x 3.8 | 2930 | 2460 | STEP |
| MSGB4-50 | 4 | 50 | 50 | 85 | 200 | 40 | 14 x 3.8 | 3650 | 2800 | STEP |
